Sunday, April 13, 2014

Dropleton – The New Semiconductor Quasiparticle

From Left to Right: (top row) Andrew E. Almand-Hunter, Hebin Li, Steven T. Cundiff, (bottom row) Martin Mootz, Mackillo Kira, Stephan.W. Koch

Authors: Andrew E. Almand-Hunter1,2, Hebin Li1, Steven T. Cundiff1,2, Martin Mootz3, Mackillo Kira3, Stephan.W. Koch3

Affiliation:
1JILA, University of Colorado & National Institute of Standards and Technology, Boulder, CO, USA
2Department of Physics, University of Colorado, Boulder, CO, USA
3Department of Physics, Philipps-University Marburg, Germany.

The description of many-particle systems becomes significantly simplified if stable configurations of subsets of the particles can be identified, particularly when the particles are interacting with one another. Examples of stable configurations range from solar systems and galaxies on an astronomical scale [1] to atoms and nuclei on a microscopic scale [2]. In solid-state systems [3], the stable configurations are referred to as “quasiparticles” that have several particle-like features, even though their physical properties are influenced by the interactions. The dropleton is the latest addition to the “periodic table” of quasiparticles in solids, as reported in our recent publication [4].

Extended crystalline solids typically contain more than 1020 interacting electrons per cm3, which makes the quantum many-body problem unsolvable based on overwhelming dimensionality. Therefore, finding quasiparticles is not only extremely useful but also instrumental in order to describe and understand the physics of solids. The “crystal electron’’ – or “Bloch electron’’ – is the simplest quasiparticle of solids. One can attribute a varying mass to an electron inside a crystal, in the same way as a swimmer’s bodyweight seems to change in water. As a quantum feature, crystal electron's effective mass not only depends on the electron-crystal interaction but also on its velocity [3]. When a single electron is removed from an ensemble of many electrons, the missing electron is also a quasiparticle called the “hole’’. The hole simply has the properties of the missing electron, such as a positive elementary charge and a negative effective mass. Conceptually, a hole resembles a bubble, i.e. particle vacancy, in water; its motion is clearly much simpler to track than that of remaining particles.

The quantum mechanically allowed electron-energy regions in solids are commonly known as energy bands and they can be separated by forbidden regions, the band gaps [3]. Without any doping and at low temperatures, a semiconductor is an insulator where all energetically low-lying bands are fully occupied by electrons and all energetically higher bands are completely free. The absorption of light transfers semiconductor electrons from the energetically highest fully occupied band – the valence band – into the originally unoccupied conduction band. Due to their opposite charge, the optically excited conduction-band electron and the simultaneously generated valence-band hole experience an attractive Coulomb interaction which may bind them to a new quasiparticle known as an exciton [5,6]. An exciton is similar in many ways to a hydrogen atom; however, it has a relatively short lifetime since the electron can return from the conduction into the valence band. In this electron-hole recombination process, the excess energy can be emitted as light or it can be transferred to the host crystal as heat.

Under suitable conditions, two excitons can bind into a molecule referred to as biexciton[7,8] which has strong analogies to the hydrogen molecule. Generally, it is an interesting open question if and in which form electron-hole pairs can form even larger clusters with quasiparticle character and how these clusters can be identified spectroscopically. One may distinguish the presence of distinct quasiparticles by the different color resonance they absorb or emit light [9-15], in the same way as atoms and molecules have distinct resonances in the absorption spectrum as fingerprints that provide a positive identification of the “culprit”.

However, identification of semiconductor quasiparticles from light absorption is not as simple as it seems. In general, an ordinary laser pulse only induces electron-hole-pair excitations whereas the more complex quasiparticles are created by the quantum mechanical many-particle interactions, yielding several possible outcomes [16] that blur the quasiparticle resonances. Since the state and the characteristic features of the excited state are very complex and depend sensitively on the detailed excitation conditions, it is generally very difficult to identify the quasiparticle signatures in spectra as long as “only” classical spectroscopy is used.

Figure 1: Classical vs. quantum-optical spectroscopy. In classical spectroscopy (left), the photons (wave symbols) are uncorrelated and they create unbound pairs of electrons (spheres) and holes (open circles). In quantum spectroscopy (right), the photons are correlated (yellow ellipse) such that they directly excite a correlated electron-hole cluster (yellow circle).

To overcome this problem, we developed the concept of quantum-optical spectroscopy [16,17] based on fundamental quantum properties of light. In general, quantized light can be described in terms of photons, i.e. the energy quanta of light. Whereas classical laser light basically contains isolated photons, i.e. no specific photon clusters, such clusters are characteristic for quantum light sources. Most important for our quasiparticle search, the cluster characteristics of the exciting light is directly transferred to the optically generated electron-hole excitations. Consequently, suitable quantum-light sources can e.g. generate predominantly excitons, or biexcitons, or even larger clusters [16,17]. In other words, one can directly excite new quasiparticles with a quantum-light source whose photon clusters match the cluster characteristics of the desired quasiparticle state. Figure 1 illustrates this main difference of classical and quantum-optical laser spectroscopy.

Even though freely adjustable quantum-light sources do not yet exist, we have demonstrated [18] that a large set of classical pump-probe spectra can be robustly projected into the desired quantum-optical spectra. To collect the data, we used short pulses to generate electrons and holes faster than they can decay. In our quasiparticle-search experiments [4], we actually apply pulses of light, produced by a laser, that are only 100 femtoseconds (1fs=10-15s) in duration. To study the types of quasiparticles that can occur in a semiconductor, beyond just electrons, holes and excitons, we use a strong pulse, known as the “pump” pulse to excite a desired number of electrons and holes. We then monitor how a weak subsequent pulse, known as the “probe” pulse, is absorbed. To observe different types of quasiparticles, we perform these measurements very carefully as we slowly increase the intensity of the pump pulse. Then each pump-pulse intensity labels a probe-absorption spectrum within the massive set of raw data that is the input to the projected quantum-optical spectrum.

When we did this experiment, we noticed already in the raw data that the light began to be absorbed at a new color as the intensity of the pump pulse increased. This new color was distinct from the color corresponding to the creation of an exciton, or of unbound pairs of electrons and holes. We initially ascribed this observation to the formation of a biexciton. However, increasing the intensity of the pump caused this new absorption feature to change color, but very surprisingly, it did so in the wrong direction, namely opposite to the shift of the absorption due to the exciton. This gave us the hint that the new quasiparticles could be dormant underneath the blurred and shifted “biexciton” resonance.

Figure 2: Revealing new energy resonances of Dropletons. Dropleton's binding energy is determined from the light absorption that is sensitive to three-photon correlations. The spectra are plotted as a function of pump pulse's photon number. The red color denotes regions with high absorption.

To reveal which quasiparticle explains this curious behavior, we projected the raw data to an absorption spectrum that is sensitive to three-photon clusters; the quantum-optical absorption spectra are shown Fig. 2 as function of pump power. The energy is expressed in terms of binding energy with respect to exciton resonance. For low photon numbers, we observed only a biexciton resonance that had a fixed binding energy around 2.2meV, as intuitively expected. By increasing the number of photons in the pump pulse, we surprisingly observed that the semiconductor starts to absorb light at completely new colors identified by the steps. We also performed measurements that could reject molecular electron-hole states as an explanation for energy quantization, and demonstrated that the new quasiparticle evolves coherently living up to 25 picoseconds (1ps=10-12s) [4].

After discovering these new energy resonances, we proceeded to identify the exact form of the new quasiparticle that matches the measured “fingerprints”. Since the quasiparticle has a stronger binding than biexciton it must contain more electron-hole pairs than biexciton, i.e. two. However, there is no quantum theory that can exactly solve the corresponding many-body problem. Therefore, we had to develop a new approach[19] to identify the new quasiparticles. More specifically, we expressed the system energy exactly in terms of pairwise electron-hole correlation function, instead of electron and hole densities that is the basis of the density functional theory [20]. Since the correlations uniquely define complicated quasiparticles, we could precisely determine the energies of different possible electron-hole configurations.

Figure 3: Illustration of a dropleton. In a dropleton, the probability distribution of the electrons and holes forms a ring-like pattern; a representative pair-correlation function is shown as a function of the electron-hole separation. The shell defines the size of the dropleton; roughly one electron-hole pair resides within each ring.

After a thorough search, all experimental observations were explained [4] only by a configuration where electrons and holes are not bound into excitons, but they rather are loosely organized, much like particles in a liquid. However, the liquid was confined inside a small bubble, which directly explained the quantization as a confinement effect. Due to liquid characteristics, quantization, and small size, we called the new quasiparticle a dropleton. The jumps in the dropleton energy levels were shown [4] to correspond to adding a new electron-hole pair to the dropleton. In total, we could detect dropletons with four, five, six, and seven electron-hole pairs and conclude that the quantum droplet size was in the range of 200nm (1nm=10-9m) in diameter.

The discovery of dropleton is the first tangible demonstration that the quantum-optical spectroscopy excites and controls quasiparticles with unprecedented accuracy. To make full use of this encouraging advancement, it will be an important future goal to develop ultrafast and strong light sources whose quantum fluctuations can be freely adjusted. Since the dropletons are brand new addition to the quasiparticle family, it is not predictable how and when they can be seen in practical use. However, all quasiparticles also influence the operation of optoelectronic devices such as laser diodes which are already used in DVD readers/writers and in optical communications. Thus, the improved control of quasiparticles will certainly enhance our ability to design these types of devices. In addition, dropletons couple strongly with quantum light, which should be extremely useful when designing lasers and devices capable of encoding and processing quantum information. This level of control of light-matter interaction will provide intriguing possibilities to test foundations of quantum mechanics as well as introduce new ways to utilize them to build devices with an incredible performance.

References:
[1] Jack J. Lissauer, "Chaotic motion in the solar system", Reviews of Modern Physics, 71, 835 (1999). Abstract.
[2] Yu. Ts. Oganessian, A. V. Yeremin, A. G. Popeko, S. L. Bogomolov, G. V. Buklanov, M. L. Chelnokov, V. I. Chepigin, B. N. Gikal, V. A. Gorshkov, G. G. Gulbekian, M. G. Itkis, A. P. Kabachenko, A. Yu. Lavrentev, O. N. Malyshev, J. Rohac, R. N. Sagaidak, S. Hofmann, S. Saro, G. Giardina, K. Morita "Synthesis of nuclei of the superheavy element 114 in reactions induced by 48Ca". Nature, 400, 242 (1999). Abstract.
[3] Charles Kittel, "Introduction to solid state physics" (Wiley & Sons, 8th Ed., 2005).
[4] A.E. Almand-Hunter, H. Li, S.T. Cundiff, M. Mootz, M. Kira, S.W. Koch, "Quantum droplets of electrons and holes". Nature, 506, 471 (2014). Abstract.
[5] J. Frenkel, "On the transformation of light into heat in solids. I". Physical Review, 37, 17 (1931). Abstract.
[6] Gregory H. Wannier, "The structure of electronic excitation levels in insulating crystals". Physical Review, 52, 191 (1937). Abstract.
[7] Murray A. Lampert, "Mobile and immobile effective-mass complexes in nonmetallic solids". Physical Review Letters, 1, 450 (1958). Abstract.
[8] J.R. Haynes, "Experimental observation of the excitonic molecule". Physical Review Letters, 17, 860 (1966). Abstract.
[9] A.G. Steele, W.G. McMullan, and M.L.W. Thewalt, "Discovery of polyexcitons". Physical Review Letters, 59, 2899 (1987). Abstract.
[10] Daniel B. Turner, Keith A. Nelson, "Coherent measurements of high-order electronic correlations in quantum wells". Nature, 466, 1089 (2010). Abstract.
[11] Carson D. Jeffries, "Electron–hole condensation in semiconductors". Science 189, 955 (1975). Abstract.
[12] Takeshi Suzuki, Ryo Shimano, "Time-resolved formation of excitons and electron–hole droplets in Si studied using terahertz spectroscopy". Physical Review Letters, 103, 057401 (2009). Abstract.
[13] R.A. Kaindl, M.A. Carnahan, D. Hagele, R. Lovenich, D.S. Chemla, "Ultrafast terahertz probes of transient conducting and insulating phases in an electron–hole gas". Nature, 423, 734 (2003). Abstract.
[14] R. P. Smith, J. K. Wahlstrand, A. C. Funk, R. P. Mirin, S. T. Cundiff, J. T. Steiner, M. Schafer, M. Kira, S. W. Koch, "Extraction of many-body configurations from nonlinear absorption in semiconductor quantum wells". Physical Review Letters, 104, 247401 (2010). Abstract.
[15] R. Huber, F. Tauser, A. Brodschelm, M. Bichler, G. Abstreiter, A. Leitenstorfer, "How many-particle interactions develop after ultrafast excitation of an electron–hole plasma". Nature, 414, 286 (2001). Abstract.
[16] Mackillo Kira, Stephan W. Koch, "Semiconductor quantum optics" (Cambridge University Press, 2011).
[17] M. Kira and S.W. Koch, "Quantum-optical spectroscopy in semiconductors". Physical Review A, 73, 013813 (2006). Abstract.
[18] M. Kira, S.W. Koch, R.P. Smith, A.E. Hunter, S. T. Cundiff, "Quantum spectroscopy with Schrödinger-cat states". Nature Physics, 7, 799 (2011). Abstract.
[19] M. Mootz, M. Kira and S.W. Koch, "Pair-excitation energetics of highly correlated many-body states", New J. Phys. 15, 093040 (2013). Full Article.
[20] David Sholl and Janice A. Steckel, "Density Functional Theory: A Practical Introduction" (Wiley, 2009).

Labels: , ,


posted by Quark @ 6:57 AM      links to this post


Sunday, April 06, 2014

Entangled Photons are Used to Enhance the Sensitivity of Microscope.

(From left to right) Ryo Okamoto, Shigeki Takeuchi, Takafumi Ono

Authors: Takafumi Ono, Ryo Okamoto, Shigeki Takeuchi

Affiliation:
Research Institute for Electronic Science, Hokkaido University, Japan,
The Institute of Scientific and Industrial Research, Osaka University, Japan.

We demonstrated a microscope whose sensitivity is enhanced by using quantum entanglement -- over the limit set by the conventional (classical) light illumination. This is the first experimental demonstration of the application of entangled photons for microscopy.

Quantum entanglement is a unique feature of quantum particles, like photons, electrons, and so on. Quantum entanglement was first introduced by Schrödinger, and later a famous debate on it occurred between Einstein and Bohr; Einstein called it `spooky action at a distance’. Now, quantum entanglement is attracting attention as the resources for quantum information technologies like quantum cryptography and quantum computation. We demonstrated that quantum entanglement is not only useful for such information technologies, but also in other broader fields, like microscopy.

Figure 1: A schematic image of the entanglement-enhanced microscope.

Some years ago, we reported the experiment of four photon interference with high visibility -- enough to beat the standard quantum limit for the phase sensitivity [2]. In that experiment, we used so called `NOON’ state, a path-entangled state where N-photon state is either in one of the two paths (and 0 photons in the opposite path). We demonstrated the quantum interference fringe using a four-photon NOON state with a high-visibility (91%) that was enough to beat the standard quantum limit of the phase sensitivity.

Perhaps the next natural step is to demonstrate entanglement-enhanced metrology. Among the applications of optical phase measurement, the differential interference contrast microscope (DIM) is widely used for the evaluation of opaque materials or biological tissues. The depth resolution of such measurements is determined by the signal-to-noise ratio (SNR) of the measurement, and the SNR is in principle limited by the standard quantum limit. In the advanced measurements using DIM, the intensity of the probe light is tightly limited for a non-invasive measurement, and the limit of the SNR has become a critical issue.

In our recent work [1], we proposed and demonstrated an entanglement-enhanced microscope, which is a confocal-type DIM where an entangled photon pair source is used for illumination. An image of a glass plate sample, where a Q shape is carved in relief on the surface with a ultra-thin step of ~17 nm, is obtained with better visibility than with a classical light source. The signal-to-noise ratio is 1.35±0.12 times better than that limited by the standard quantum limit. The success of this research will enable more highly sensitive measurements of living cells and other objects, and it has the potential for application in a wide range of fields, including biology and medicine.
Figure 2: (a) Atomic force microscope (AFM) image of a glass plate sample (BK7) on whose surface a Q shape is carved in relief with an ultra-thin step using optical lithography. (b) The section of the AFM image of the sample, which is the area outlined in red in a. The height of the step is estimated to be 17.3nm from this data. (c) The image of the sample using an entanglement-enhanced microscope where two-photon entangled state is used to illuminate the sample. (d) The image of the sample using single photons (a classical light source).

We believe this experimental demonstration is an important step towards entanglement- enhanced microscopy with ultimate sensitivity, using a higher NOON state or other quantum states of light. There are some other related works harnessing such nonclasical light for metrology[3-5].

References:
[1] Takafumi Ono, Ryo Okamoto, Shigeki Takeuchi, “An entanglement-enhanced microscope”. Nature Communications, 4, 2426 (2013). Abstract.
[2] Tomohisa Nagata, Ryo Okamoto, Jeremy L. O'Brien, Keiji Sasaki, Shigeki Takeuchi, “Beating the standard quantum limit with four-entangled photons”. Science, 316, 726–729 (2007). Abstract.
[3] Andrea Crespi, Mirko Lobino, Jonathan C. F. Matthews, Alberto Politi, Chris R. Neal, Roberta Ramponi, Roberto Osellame, Jeremy L. O’Brien, “Measuring protein concentration with entangled photons”. Applied Physics Letters, 100, 233704 (2012). Abstract.
[4] Florian Wolfgramm, Chiara Vitelli, Federica A. Beduini, Nicolas Godbout, Morgan W. Mitchell, “Entanglement- enhanced probing of a delicate material system”. Nature Photonics, 7, 28–32 (2013). Abstract.
[5] Michael A. Taylor, Jiri Janousek, Vincent Daria, Joachim Knittel, Boris Hage, Hans-A. Bachor, Warwick P. Bowen, “Biological measurement beyond the quantum limit”. Nature Photonics, 7, 229–233 (2013). Abstract.

Labels: ,


posted by Quark @ 6:59 AM      links to this post


Sunday, March 30, 2014

Polarization-controlled Photon Emission
from Site-controlled InGaN Quantum Dots

Left to Right: (top row) Chih-Wei Hsu, Anders Lundskog, K. Fredrik Karlsson, Supaluck Amloy. (bottom row) Daniel Nilsson, Urban Forsberg, Per Olof Holtz, Erik Janzén.

Authors: Chih-Wei Hsu1, Anders Lundskog1, K. Fredrik Karlsson1, Supaluck Amloy1,2, Daniel Nilsson1, Urban Forsberg1, Per Olof Holtz1, Erik Janzén1

Affiliation:
1Department of Physics Chemistry and Biology (IFM), Linköping University, Sweden.
2Department of Physics, Faculty of Science, Thaksin University, Phattalung, Thailand.

A common requirement to realize several optoelectronic applications, e.g. liquid-crystal displays, three-dimensional visualization, (bio)-dermatology [1] and optical quantum computers [2], is the need of linearly-polarized light for their operation. For existing applications today, the generation of linearly-polarized light is obtained by passing unpolarized light through a combination of polarization selective filters and waveguides, with an inevitable efficiency loss as the result. These losses could be drastically reduced by employment of sources, which directly generate photons with desired polarization directions.

Quantum dots (QDs) have validated their important role in current optoelectronic devices and they are also seen as promising as light sources for generation of “single-photons-on-demand”. Conventional QDs grown via the Stranski-Krastanov (SK) growth mode are typically randomly distributed over planar substrates and possess different degrees of anisotropies. The anisotropy in the strain field and/or the geometrical shape of each individual QD determines the polarization performance of the QD emission. Accordingly, a cumbersome post-selection of QDs with desired polarization properties among the randomly-distributed QDs is required for device integration [3]. Consequently, an approach to obtain QDs with controlled site and polarization direction is highly desired.
Figure 1. Magnified SEM images of GaN EHPs with various α. The values of α are defined as the angles between the long axis of EHPs and the underlying GaN template.

Here, we demonstrate an approach to directly generate a linearly-polarized QD emission by introducing site-controlled InGaN QDs on top of GaN-based elongated hexagonal pyramids (GaN EHPs). The polarization directions of the QD emission are demonstrated to be aligned with the orientations of the EHPs (Figure 1). The reliability and consistency for this architecture are tested by a statistical analysis of InGaN QDs grown on GaN EHP arrays with different in-plane orientations of the elongations. Details of the process and optical characterizations can be found in our resent publication [4].

Figure 2. a) µPL spectra of EHPs with the polarization analyzer set to θmaxmin), by which the maximum (minimum) intensity of sharp emission peaks are detected. b) Distribution histograms of measured polarization directions from the GaN EHPs for various α.

Figure 2a shows representative polarization-dependent micro-photoluminescence (µPL) spectra from a EHP measured at 4o K. A broad emission band peaking at 386 nm and several emission peaks in the range between 410 and 420 nm are observed. These sharp emission lines are originating from the multiple QDs formed on top of the GaN EHP. Despite the formation of multiple QDs on a GaN EHP, the emission peaks from all QDs tend to be linearly-polarized in the same direction as revealed in Figure 3a and all peaks have their maximum and minimum intensities in the same direction, θ. The correlation between the outcome of the polarization-resolved measurements and the orientations of GaN EHPs (as defined by α) reveals that the polarization direction is parallel to the elongation (α≅φ in Figure 2b). A polarization guiding (α≅φ) is unambiguously revealed for GaN EHPs with α = 0o, 60o and 120o. For the remaining group of GaN EHPs with α = 30o, 90o and 150o, preferential polarization directions are seemly revealed, but α≅φ is less strictly obeyed. The polarization guiding effect and the high degree of polarization are further elucidated in the following.

Figure 3. a) Statistical histogram showing the overall measured degree of polarization from GaN EHPs. b) The computed degree of polarization plotted as a function of the split-off energy. The QD shape is assumed to be lens-shaped with an in-plane asymmetry of b/a= 0.8. The single particle electron (hole) eigenstates are obtained from an effective mass Schrödinger equation (with a 6 band k•p Hamiltonian), discretized by finite differences. The Hamiltonians include strain and internal electric fields originating from spontaneous and piezoelectric polarizations. The polarized optical transitions are computed by the dipole matrix elements.

The polarization direction of the ground-state-related emission from the QDs reflects the axis of the in-plane anisotropy of the confining potential, concerning both strain and/or QD shape [5]. The same polarization direction monitored for the different QDs indicates that all grown QDs possess unidirectional in-plane anisotropy. The polarization control observed in our work can be explained in three ways: (1) the GaN EHPs transfer an anisotropic biaxial strain field to the QDs resulting in the formation of elongated QDs. The direction of the strain field in the EHPs should be strongly correlated with α. (2) Given that the top parts of the GaN EHPs are fully strain relaxed, as concluded for the GaN SHPs [6], the asymmetry induced by a ridge will result in an anisotropic relaxation of the in-plane strain of the QDs on the ridge. The degree of relaxation is higher along the smallest dimension of the top area, i.e. along the direction perpendicular to the ridge elongation, resulting in a ground state emission of the QD being polarized in parallel with the ridge. (3) The edges of the ridges form a Schwoebel–Ehrlich barrier, which prevents adatoms of diffusing out from the (0001) facet [7,8]. Since the adatoms have larger probability to interact with an edge barrier parallel rather than orthogonal to the ridge elongation, the adatoms will preferentially diffuse parallel to the ridge. As the strain and the shape of the QDs are not independent factors and accurate structural information of the QDs is currently unavailable, the predominant factors determining the polarization is to be verified.

The polarization degree of the III-Ns is more sensitive to the in-plane asymmetry compared to other semiconductor counterparts due to the significant band mixing and the identical on-axis effective masses of the A and B bands in the III-N [5]. A statistical investigation of the value of P performed on 145 GaN EHPs reveals that 93% of the investigated GaN EHPs possess P > 0.7 with an average value of P = 0.84 (Figure 3a). The polarization of the emissions is related to the QD asymmetry determined by the anisotropy of the internal strain and electric fields, as well as by the structural shape of the QD itself [5]. Numerical computations predict a high degree of polarization for small or moderate in-plane shape anisotropies of GaN and InGaN QDs [9]. This is related to the intrinsic valence band structure of the III-Ns. In particular, the split-off energy has been identified as the key material parameter determining the degree of polarization for a given asymmetry. Figure 3b shows the computed degree of polarization plotted against a variation of the split-off energy. Given a fixed asymmetry of the QDs, it is concluded that the material with the smallest split-off energy exhibits the highest degree of polarization. The high degree of polarization observed for InGaN QDs can be rationalized by the small split-off energies of InN and GaN, resulting in an extreme sensitivity to the asymmetry. Such a characteristic implies its inherent advantage for the generation of photons possessing a specific polarization.

In summary, we have demonstrated an effective method to achieve site-controlled QDs emitting linearly-polarized emission with controlled polarization directions by growing InGaN QDs on top of elongated GaN pyramids in a MOCVD (metal organic chemical vapor deposition) system. The polarization directions of the QD emission can be guided by the orientations of the underlying elongated GaN pyramids. Such an effect can be realized as the elongated GaN pyramids provide additional in-plane confinement for the InGaN QDs implanting unidirectional in-plane anisotropy into the QDs, which subsequently emit photons linearly-polarized along the elongated direction of the GaN EHPs.

References:
[1] Zeng Nan, Jiang Xiaoyu, Gao Qiang, He Yonghong, Ma Hui, "Linear polarization difference imaging and its potential applications". Applied Optics, 48, 6734-6739 (2009). Abstract.
[2] E. Knill, R. Laflamme, G.J. Milburn, "A scheme for efficient quantum computation with linear optics". Nature, 409, 46-52 (2001). Abstract.
[3] Robert J. Young, D.J.P. Ellis, R.M. Stevenson, Anthony J. Bennett, "Quantum-dot sources for single photons and entangled photon pairs". Proceedings of the IEEE, 95, 1805–1814 (2007). Abstract.
[4] Anders Lundskog, Chih-Wei Hsu, K Fredrik Karlsson, Supaluck Amloy, Daniel Nilsson, Urban Forsberg, Per Olof Holtz, Erik Janzén, "Direct generation of linearly-polarized photon emission with designated orientations from site-controlled InGaN quantum dots". Light: Science & Applications 3, e139 (2014). Full Article.
[5] R. Bardoux, T. Guillet, B. Gil, P. Lefebvre, T. Bretagnon, T. Taliercio, S. Rousset, F. Semond, "Polarized emission from GaN/AlN quantum dots: single-dot spectroscopy and symmetry-based theory". Physical Review B, 77, 235315 (2008). Abstract.
[6] Q.K.K. Liu, A. Hoffmann, H. Siegle, A. Kaschner, C. Thomsen, J. Christen, F. Bertram, "Stress analysis of selective epitaxial growth of GaN". Applied Physics Letters, 74, 3122-3124 (1999). Abstract.
[7] O. Pierre-Louis, M.R. D’Orsogna, T.L. Einstein, "Edge diffusion during growth: The kink Schwoebel-Erhlich effect and resulting instabilities". Physical Review Letters, 82, 3661-3664 (1999). Abstract.
[8] S.J. Liu, E.G. Wang, C.H. Woo, Hanchen Huang, "Three-dimensional Schwoebel–Ehrlich barrier". Journal of Computer-Aided Materials Design, 7, 195–201 (2001). Abstract.
[9] S. Amloy, K.F. Karlsson, T.G. Andersson, P.O. Holtz, "On the polarized emission from exciton complexes in GaN quantum dots". Applied Physics Letters, 100, 021901 (2012). Abstract.

Labels: ,


posted by Quark @ 9:11 AM      links to this post


Sunday, March 23, 2014

Invisibility Cloak Goes Three-Dimensional for Heat

Authors: Hongyi Xu1, Xihang Shi1, Fei Gao1, Handong Sun1,2, Baile Zhang1,2

Affiliation:
1Division of Physics and Applied Physics, School of Physical and Mathematical Sciences, Nanyang Technological University, Singapore.
2Centre for Disruptive Photonic Technologies, Nanyang Technological University, Singapore.

While the topic of invisibility has long been investigated in optics-related topics, it is for the first time that invisibility cloaking is realized for heat in a three-dimensional (3D) thermal space, according to a recent research result[1] published by our group at Nanyang Technological University, Singapore.

Thermal invisibility was initially inspired by the concept of Transformation Optics [2, 3], a method that can control light propagation with a coordinate transformation in a 3D optical space, which in general requires optical metamaterials with exotic constitutive parameters (e.g. extremely large or extremely small anisotropic permittivity and permeability). Despite the inspiring elegance of 3D optical invisibility cloaking theory, its experimental realizations have been mainly limited to two dimensions (2D), because of the widely acknowledged tremendous difficulties in constructing optical metamaterials with stringent parameters in 3D.

Similarly, the recent development of thermal invisibility cloaking based on transformation thermodynamics were firstly demonstrated in 2D [4, 5]. The method, similar to transformation optics, requires thermal metamaterials with anisotropy and inhomogeneity, being difficult in 3D.

Researchers in Nanyang Technological University successfully bypassed the problem by taking advantage of the difference between heat (a diffusion phenomenon) and light (a wave phenomenon), and experimentally demonstrated the world’s first ultra-thin 3D thermal cloak that shields an air bubble in a stainless steel from external conductive heat flux [1]. The technology can protect a 3D object from heat flux without distorting the external temperature distribution by simply using an ultra-thin layer of thermal metamaterial made of copper with carefully designed thickness.

The implementation process of thermal cloak is illustrated in Fig.1. A hemi-spherical hole with radius of 0.51 cm was drilled by electrical discharge machining in a half stainless steel block with dimension of 2×2×1 cm. A thin disk of copper was punched into the hemi-spherical hole by a molding rod (Fig 1a), to form a copper shell (Fig. 1b) with homogeneous thickness of 100 μm. Two identical half blocks were further combined together to form a complete 3D thermal cloak (Fig. 1c), with dimension of 0.5/0.51 cm for the inner/outer radius of the copper spherical layer, and 2×2×2 cm for the complete stainless steel block.

Figure 1. Illustration of the Fabrication of a 3D thermal cloak. a, Molding process of half of the 3D thermal cloak: (a) Thin copper disk is punched into the hemispherical hole in the stainless steel block. (b) Illustration and snapshot of half of the thermal cloak after molding. (c) Illustration and snapshot of the full cloak by combining two half blocks. The red/blue plate represents high/low temperature at the bottom/top surface [1].

In the experimental characterization, a hot plate (red color, Fig. 1c) and an ice tank (blue color, Fig. 1c) were closely attached to the bottom and top surface of the thermal cloak. When heat diffused from bottom to top, the temperature at the cross-section surface was captured by a thermal camera. The dynamic process of heat transfer from the beginning to the moment near thermal equilibrium was recorded in a movie clip:


The temperature distributions at the beginning time and at the moment near thermal equilibrium are shown in Fig. 2. In Fig. 2a and 2d (cases of background), the temperature distribution is homogeneous across the entire surface, indicating that heat diffuses through the stainless steel smoothly. In Fig. 2b and 2e (cases without thermal cloak), the distribution of temperature is distorted (being ‘bent’ towards the air bubble) and a relatively cool region is left behind the air bubble, indicating that part of heat flux has been blocked by the air bubble. In Fig. 2c and Fig. 2f (cases with thermal cloak), the temperature distribution outside the air bubble is restored to norm, as if the air bubble did not exist, indicating the cloaking effect for heat flux.
Figure 2. Characterization of conductive thermal cloaking for transient homogeneous thermal flux. (a-c) Temperature distributions for the moment of 0.5 min at the beginning of heat transfer. (d-f) Temperature distributions for the moment of 4.5 min close to thermal equilibrium. (a&d) Temperature distributions in the pure background without any air bubble or cloak. (b&e) Temperature distributions when an air bubble without the cloak is present. (c&f) Temperature distributions when the air bubble is cloaked by the ultra-thin cloak. In b-c and e-f, the dotted circles indicate the position of the air bubble, while the dotted circles in a and d are merely for comparison [1].

This thermal invisibility cloak is the first demonstration in 3D that heat flux can be effectively controlled by thermal metamaterials. Application wise, effective control of heat is an important subject in modern semiconductor industries, where the exponential increase of package density is generating more and more heat in a unit space. The heat generated jeopardized the performance and lifetime of semiconductor devices, accounting for over 50 percent of electronic failures [6]. With effective heat control technologies based on thermal metamaterials, it is possible to develop efficient heat dissipation solutions to thermal problems in semiconductor industries.

References:
[1] Hongyi Xu, Xihang Shi, Fei Gao, Handong Sun, Baile Zhang, "Ultrathin Three-Dimensional Thermal Cloak", Physical Review Letters, 112, 054301 (2014). Abstract.
[2] Ulf Leonhardt, "Optical Conformal Mapping", Science, 312, 1777-1780 (2006). Abstract.
[3] J. B. Pendry, D. Schurig, D. R. Smith, "Controlling Electromagnetic Fields", Science, 312, 1780-1782 (2006). Abstract.
[4] Supradeep Narayana, Yuki Sato, "Heat Flux Manipulation with Engineered Thermal Materials", Physical Review Letters, 108, 214303 (2012). Abstract.
[5] Robert Schittny, Muamer Kadic, Sebastien Guenneau, Martin Wegener, "Experiments on Transformation Thermodynamics: Molding the Flow of Heat", Physical Review Letters, 110, 195901 (2013). Abstract.
[6] Shanmuga Sundaram Anandan, and Velraj Ramalingam, "Thermal Management of Electronics: A Review of Literature," Thermal Science, 12, 5-26 (2008). Full Article.

Labels:


posted by Quark @ 3:45 AM      links to this post


Sunday, March 16, 2014

Trasparent Electronics Wrapped Around Hairs and Transferred on Plastic Contact Lens

(Left to Right) Giovanni A. Salvatore, Niko Münzenrieder, Gerhard Tröster

Authors: Giovanni A. Salvatore, Niko Münzenrieder, Gerhard Tröster

Affiliation: Electronics Laboratory, Swiss Federal Institute of Technology, Zurich, Switzerland.

While silicon is bulky and rigid, plastic electronics is soft, deformable and lightweight. Flexible electronic devices like rollable displays, conformable sensors, plastic solar cells and flexible batteries could enable applications that would be impossible to achieve by using the hard electronics of today. So far, the effective commercialization of such technology has been mainly prevented by cost and performance constraints. However, for some applications, the specific functionalities provided by flexible, biocompatible, conformable and light plastic electronics are much more important than the aforementioned obstacles and future scenarios can be realistically foreseen. The development of flexible electronic circuits plays a crucial role in all such applications. Flexibility can be achieved by direct fabrication on plastic foil [1], by peeling off a polymer layer spin coated on a rigid substrate [2], by transfer printing [3] or by spalling the thin top layer from a crystalline silicon wafer after device fabrication [4].

The scenario is even more heterogeneous when looking at the variety of materials employed for the active layers. Inorganic materials including silicon nanomembranes [5] or nanowires [2], organic materials [6] or amorphous oxides [7] are all possible options. Recently electronics on very thin substrates has shown remarkable bendability, conformability and lightness, which are important attributes for biological tissues sensing, wearable or implantable devices [5,8,9]. All the mentioned approaches and materials offer advantages and suffer from limitations. A unique and universal integration scheme has not been developed yet and at the moment the choice mainly depends on specific applications.

In our recent work [10] we propose a wafer-scale process scheme to realize ultra-flexible, lightweight and transparent electronics on top of a 1μm thick parylene film which is released from the carrier substrate after the dissolution in water of a Poly-Vinyl-Alcohol (PVA) layer. The thin substrate ensures extreme flexibility, which is demonstrated by transistors which continue to work when wrapped around human hairs. In parallel, the use of amorphous Indium Gallium Zinc Oxide (a-IGZO) as semiconductor and high-k dielectric enables the realization of analog amplifiers operating at 12V and above 1MHz. The possibility to implement such scheme at wafer scale and the use of a-IGZO could represent a good compromise between large area integration and performance and, hence, a valid alternative to similar reported approaches [5, 9]. After the release, electronics can be transferred onto any object, surface and on biological tissues like human skin and plant leaves.

We fabricate Thin Film Transistors (TFTs) and circuits on top of a 1μm thick parylene film. Parylene has been chosen because it is biocompatible and resistant to acetone and chemicals necessary for lift-off and etching process steps. In our experiments, PVA constitutes the first soluble layer needed to release, in water, the silicon wafer used as support during the fabrication (Fig.1b-e). Depending on the application, an additional Poly-Vinyl-Acetate (PVAc) film is added to improve the adhesion and enable the removal of electronics after use.

The devices are formed by Indium Gallium Zinc Oxide which is used as semiconductors and ensure electron mobility greater than 10cm2/Vs, transparency in the visible spectrum and large area deposition. The insulator is Al2O3 which has excellent dielectric properties. The contacts are made up by thin layer of chromium and gold. We also fabricated fully transparent devices in which metal contacts are replaced by Indium Tin Zinc Oxide (Fig.1). The maximum process temperature reached during the fabrication is 150°C. The final thickness of the TFT structure is 145nm for the non-transparent TFTs and 175nm for the transparent ones. In order to test and prove the reliability of our approach, we also designed and fabricated analog amplifiers based on the previously described TFTs.
Figure 1: Structure of thin film transistors fabricated on a silicon carrier chip covered with two sacrificial layers and a non-soluble layer which is parylene in our experiments. Poly-Vinyl-Alcohol (PVA) is water soluble and enables the release of the thin parylene membrane from the silicon substrate. Poly-Vinyl-Acetate (PVAc) film is added to improve the adhesion and enable the removal of electronics after use. Transistors and circuits are fabricated by using a-IGZO as semiconductor and Al2O3 as dielectric. Gold is used for the contacts in non-transparent devices (left in the picture) while ITO is used in case of the transparent version of the device (right).

It is worth mentioning that the use of rigid supports (glass or silicon) during the fabrication, mitigate some issues, like substrate thermal expansion or water absorption, which are encountered in case of direct fabrication on foils and which limit the feature resolution and alignment, therefore, yield and performance.

After the fabrication, the chip is put in water to selectively dissolve the PVA layer and release the parylene membrane. For a 2-inch wafer this operation takes approximately 30 minutes after which the circuits are floating on water. The membrane can then be fished and transferred onto the final destination substrate which can be any arbitrary rigid or flexible support or any organic or inorganic surface (Fig. 2).
Figure 2: The proposed process scheme can be implemented at wafer scale. Here, we demonstrate the feasibility of such approach in the case of a 2-inch wafer. The water starts dissolving the PVA layer from the borders of the wafer and slowly proceeds towards the center. The whole releasing procedure takes approximately 30 minutes after which the wafer sinks while the membrane floats on water. After the release of the hosting support, the membrane is fished and transferred onto flexible and elastic foils, textiles, biological tissues and implantable devices.

The thin substrate ensures extreme flexibility and conformability. In order to experimentally investigate the ultimate limit of the bending stability, we transferred the membrane on top of a glass substrate where some fragments of human hairs, which have a radius of about 50μm, had been previously placed. TFTs having the gate region bent around the hairs are fully operational. The mechanical properties of the thin substrate are further investigated by transferring the devices onto a 100μm thick polypropylene foil. This facilitates the handling and manipulation of the membrane while minimizing the strain induced by the substrate, thanks to the poor adhesion between polypropylene and parylene. The membrane on the polypropylene foil is folded to a radius of 750μm (Fig.3c), then repeatedly crumpled in the hands (Fig.3d) and finally re-flattened (Fig.3e). After the curling, we were able to measure only the non-transparent transistors, while none of the transparent devices was functioning. We, in fact, observed cracks in the ITO layer -- most probably due to induced strain after the release.
Figure 3: (a) Scanning electron microscopy picture of transistors wrapped around three fragments of human hairs placed on a glass support. The thin membrane ensures high flexibility and conformability and it wraps around the hairs which have a radius of approximately of 50μm (tensile strain, ε=0.4%). (b) Optical microscope picture of the area highlighted by the white box in a. (c, d, e) The membrane is transferred on a 100μm thick polypropylene foil which is folded in hand (bending radius is about 750μm) aggressively crumpled in hands and then re-flattened. The devices are still working either when bent around the hair and when curled by hands.

The membrane is also light, and biocompatible. To design a concrete application which takes advantages of such capabilities, we transferred the parylene membrane, with on top transparent transistors and strain gauge sensors, on a commercially available plastic contact lens (Fig.4). After transferring the lens onto an artificial eye, TFTs continue to function and could be used for signal amplification in future developments. In the design of a real system particular attention must be paid to the packaging which has to mitigate or eliminate the effects of the humor aqueous of the eye.

Figure 4: The membrane with on top transparent TFTs and gold strain gauge sensors is transferred on a plastic contact lens held between two fingers. Such technology could find application as smart contact lenses able to monitor and diagnose glaucoma disease.

Thereby, the developed technology could find application as smart contact lenses able to monitor and diagnose glaucoma disease and it could offer significant advantages over existing solutions [11] in terms of thickness, lightness and transparency and, hence, comfort for the patient. Future works should be focused on the development of wireless communication schemes and on the powering of the system.

References:
[1] N. Münzenrieder, L. Petti, C. Zysset, G.A. Salvatore, T. Kinkeldei, C. Perumal, C. Carta, F. Ellinger, G. Troster, “Flexible a-IGZO TFT amplifier fabricated on a free standing polyimide foil operating at 1.2 MHz while bent to a radius of 5 mm”, Proceedings of International Device meeting IEDM (2012). Abstract.
[2] Kuniharu Takei, Toshitake Takahashi, Johnny C. Ho, Hyunhyub Ko, Andrew G. Gillies, Paul W. Leu, Ronald S. Fearing, Ali Javey, “Nanowire active-matrix circuitry for low-voltage macroscale artificial skin”, Nature Materials, 9, 821-826 (2010). Abstract.
[3] Matthew A. Meitl, Zheng-Tao Zhu, Vipan Kumar, Keon Jae Lee, Xue Feng, Yonggang Y. Huang, Ilesanmi Adesida, Ralph G. Nuzzo, John A. Rogers, “Transfer printing by kinetic control of adhesion to an elastomeric stamp", Nature Materials, 5, 33 - 38 (2006). Abstract.
[4] Davood Shahrjerdi, Stephen W. Bedell, “Extremely Flexible Nanoscale Ultrathin Body Silicon Integrated Circuits on Plastic”, Nano Letters, 13, 315-320 (2012). Abstract.
[5] Dae-Hyeong Kim, Jong-Hyun Ahn, Won Mook Choi, Hoon-Sik Kim, Tae-Ho Kim, Jizhou Song, Yonggang Y. Huang, Zhuangjian Liu, Chun Lu, John A. Rogers, "Stretchable and Foldable Silicon Integrated Circuits". Science, 320, 507-511 (2008). Abstract.
[6] Tsuyoshi Sekitani, Ute Zschieschang, Hagen Klauk, Takao Someya, "Flexible organic transistors and circuits with extreme bending stability". Nature Materials, 9, 1015-1022 (2010). Abstract.
[7] Kenji Nomura, Hiromichi Ohta, Akihiro Takagi, Toshio Kamiya, Masahiro Hirano, Hideo Hosono, “Room-temperature fabrication of transparent flexible thin-film transistors using amorphous oxide semiconductors”, Nature, 432, 488-492 (2004). Abstract.
[8] Martin Kaltenbrunner, Matthew S. White, Eric D. Głowacki, Tsuyoshi Sekitani, Takao Someya, Niyazi Serdar Sariciftci, Siegfried Bauer, "Ultrathin and lightweight organic solar cells with high flexibility". Nature Communications, 3:770, (2012). Abstract.
[9] Martin Kaltenbrunner, Tsuyoshi Sekitani, Jonathan Reeder, Tomoyuki Yokota, Kazunori Kuribara, Takeyoshi Tokuhara, Michael Drack, Reinhard Schwödiauer, Ingrid Graz, Simona Bauer-Gogonea, Siegfried Bauer, Takao Someya, "An ultra-lightweight design for imperceptible plastic electronics". Nature, 499, 458-463, (2013). Abstract.
[10] Giovanni A. Salvatore, Niko Münzenrieder, Thomas Kinkeldei, Luisa Petti, Christoph Zysset, Ivo Strebel, Lars Büthe, Gerhard Tröster, “Wafer-scale design of lightweight and transparent electronics that wraps around hairs”, Nature communications, 5:2982 (2014). Abstract.
[11] www.sensimed.ch
